Description
1500 - 2000 - 3000 - 4000 - 5000 - 6000 - 8000 - 10000 liters
TECHNICIAL SPECIFICATIONS
- CrNi 304 quality stainless steel is used.
- ROLLBOND evaporator welded with SPECIAL LASER WELDING TECHNOLOGY on 2 mm inner wall is used.
- The inner wall consists of 2 mm sheet metal.
- The outer wall consists of 1.5 mm sheet thickness.
- The cooling unit and the tank body are mounted on a solid chassis or on a separate cooling chassis from the tank.
- There is a 1.1 KW 28d/d reducer and a stainless steel mixer blade attached to it, 60 mm thick HCFC-free water-based high density polyurethane is used in insulation.
- Butterfly valve is used at the product outlet.
- 400 mm or 500 mm diameter openable round manhole cover is used. There is a manual washing line and a CIP washing ball.
- It is designed to leave zero inside during discharging.
- Welded areas are 1 class laser and argon welding.
- Class smooth polishing is applied.
COOLING SYSTEM
- It provides fast and frost-free cooling according to the minimum amount of milk.
- R-404A refrigerant is used.
- Each milking (35°C - 38°C) of the milk cooling tanks provides the opportunity to cool the milk from 35°C to 4°C at ambient temperature.
- It is designed in accordance with optional 2'4, 4, 6 milking systems.
ELECTRICAL GROUP
- There are electrical panels with IP 65 protection class.
- It has the opportunity to work with 220 Volt - 380 Volt energy.
- There is a temperature display with a digital thermometer.
- There is an electronic control card that allows the operation of the specially designed, easy-to-use tank and the milk temperature to be controlled.
- Automatic mixing program with special software, after the milk reaches the desired set value, the mixer working time can be adjusted at desired intervals.
OPTION
- Digital weighing system can be assembled.
- Milk transfer pump can be installed.
- Automatic washing system can be installed.
