Description
125 - 200 - 300 - 500 liters
TECHNICIAL SPECIFICATIONS
Cr Ni 304 quality stainless steel is used.
ROLLBOND evaporator welded with SPECIAL LASER WELDING TECHNOLOGY on 2 mm inner wall is used.
The inner wall consists of 15 mm sheet thickness.
The outer wall consists of 1mm sheet thickness.
The cooling unit and the tank body are mounted on a solid chassis.
There is a 15 W - 25 W 28d/d reducer and a stainless steel mixer blade attached to it.
Water-based, high-density polyurethane with a thickness of 50 mm without HCFC is used in the insulation.
A butterfly valve is used at the product outlet, and elbows suitable for optional use are produced.
One-piece spring cover system is used.
There is a Ø 200 mm covered product inlet on the cover.
It is designed to leave zero liquid inside during discharge.
Welded areas are 1st class laser and argon welding and 1st class smooth polishing is applied.
Tanks have adjustable feet.
COOLING SYSTEM
It provides fast and frost-free cooling according to the minimum amount of milk.
R-404A refrigerant is used.
Each milking (35°C -38°C) of the milk cooling tanks provides the opportunity to cool the milk from 35°C to 4°C at ambient temperature.
It is designed in accordance with the optional 2, 4, 6 milking system.
ELECTRICAL GROUP
There are electrical panels with IP 65 protection class.
It has the opportunity to work with 220 Volt energy.
There is a temperature indicator with a digital thermometer.
There is an electronic control card that allows the operation of the specially designed, easy-to-use tank and the milk temperature to be controlled.
After the automatic mixing program with special software reaches the desired set value, the mixer working time can be adjusted at desired intervals.
OPTION
Digital weighing system can be installed.
Milk transfer pump can be installed.
